ANT 400 Low Smoke Halogen Free 50 Ohm Coaxial Cable
£5.36 £4.47
In stock
SKU
ANT400-LSHF-50
Select from our 400 range of LMR Times Micrwave and the equivalent ANT Antennax 50 ohm RF coaxial cable.
Multiple quantities ordered will be supplied in one continual length upto 100m.
PRICED PER METRE
Available option are Standard, Ultraflex, Low Smoke Halogen Free, Fire Retardent and Fire Retardent Direct Burial options.
| SKU | ANT400-LSHF-50 |
|---|---|
| Cable Options | ANT 400 LSHF |
| Ohms Ω | 50 |
| Velocity % | 85 |
| Inner Conductor (mm) | 1/2.74 |
| Dielectric Diameter (mm) | 7.24 |
| Dielectric Material | Foam PE |
| Screen Material (1st) | Aluminium Tape |
| Screen Material (2nd) | Tinned Copper |
| Jacket Material | LSHF |
| Overall Diametre (mm) | 10.3 |
Write Your Own Review
| Icon | Label | Description | Type | Size | Download |
|---|---|---|---|---|---|
 | ANT400 50Ω LSHF | 419 KB | Download |
